Say HF-365FR et sakey ya automatikon panagputot na foil ya ginawa parad panagputot na copper foil, aluminum foil, tan arum niran manipis ya metal ya strips. Saya so manunan uusaren ed pangiparaan na saray foil layers parad copper flexible busbars, aluminum flexible connectors, battery interconnects, tan arum niran laminated conductive components.
Say makina et mankokombina na PLC control, touchscreen operation, servo-driven feeding, tan apat-istasyon na materyal ya unwinding. Say karukey na panagputot, karakel na batch, tan kapeles na panag-opera et nayarin direktan i-set panamegley na touchscreen. Anggad apatiran rolyo so nayarin kargaan tan iproseso ed loob na parehon siklo na panagputot, kanian say makina et matukoy parad batch production ya mangilalanor na dakel a rolyo na pareho odino mipadparan foil.
No ikompara ed manual ya panagsukat tan panagputot o panagproseso na sakey a rolyo ed sakey a panaon, say HF-365FR et ontulong pian nabawasan so pandurumaan na karukey, ag-inkaparpareho na gilig, panag-asikaso na materyales, tan saray lingo ya mandedepende ed operator-. Say incremental-length programming, production data retention, tan pause-and-resume functions so manggagawa ed satan ya matukoy parad pangiparaan na copper tan aluminum foil antis na flexible busbar welding.
Akin ya say Flexible Busbar Production et Mankaukolan na Dedicated Foil Cutting Machine
Say copper tan aluminum foil et manipis, malambot, tan mainomay ya naderal. No say panagpakan, panag-hold na materyal, odino say panag-awit na blade et ag-establi, pigaran problema so nayarin nagawa:
- Saray agmantutunosan ya karukey na foil ya mangaamper ed saray layer ya man-align na susto;
- Saray kulot, kurti, odino burred ya gilig;
- Say materyal ya onkukurang legan na panagpakan, ya manresulta ed saray anggulon sugat;
- Abeba so produktibo no saray rolyo et kaukolan ya iproseso ya indibidual;
- Kaaruman ya scrap kayari na pangitunda odino pangigapo lamet na produksyon;
- Say materyales et manlalaok-ups no saray nanduruman karukey et manual ya i-sort.
Say HF-365FR et mangilaktip na roll winding, guiding, servo feeding, material clamping, tan cut-to-length processing. No akakarga la ray rolyo tan niloob la ray parametro na produksyon, automatikon nasumpal na makina so siklo na panagputot, ya mamawas ed paulit-ulit ya manual ya panagsukat tan say pandurumaan ya mandedepende ed operator.
Mitongtong ed saray inhinyero mi
Saray Materyales ya Matukoy parad HF-365FR
Say makina et adesinyo parad panag-cross-cutting na manipis a metal ya iiter ed saray rolyo. Saray kaslakan a materyales et kaiba so:
- Bare copper foil;
- Tin-plated copper foil;
- Aluminium foil;
- Manipis a gansa;
- Manipis ya aluminum strip;
- Foil ya uusaren ed saray laminated flexible connectors;
- Arum nin manipis iran metal ya walay apaneknekan ya kapal tan inka-malet.
Say estandarten kapal na materyal et 0.01-0.3 mm, tan say epektibon kalapar na panagputot et 1-365 mm. No say materyal et walay coating, protective film, adhesive layer, odino mas malet nen say kaslakan ya copper o aluminum foil, mas maabig so sample cutting antis ya nasumpal so configuration na makina.
Say HF-365FR et aliwan parad pangkabilugan a makinan panagputot parad makapal iran busbar a gansa, plato na aluminum, odino panagputot na electrode na baterya. Saray aplikasyon ya walad paway na estandarten kapal, kalapar, odino inka-malet et mankaukolan na nikaduman panangusisa ed blade, hold-down mechanism, feeding system, tan istruktura na makina.
Saray kaslakan ya aplikasyon
Panagparaan na Copper Foil parad Flexible Busbars
Saray copper flexible busbars et kaslakan ya nagagawa diad pangipila na dakel a layer na manipis a copper foil tan pangikasakey ed duaran sampot panamegley na diffusion welding, resistance welding, odino arum nin matukoy a proseso. Say karukey tan kondisyon na gilig na kada foil layer et mangaapekta ed panag-stack, pangiposisyon, pangi-compress, tan say inka-welding.
Say HF-365FR et tuloytuloy ya manpuputer na copper foil unong ed akaprograman karukey tan karakel, ya mangiiter na mas pareparehon materyales parad layer stacking, end alignment, tan welding. Say apatiran istasyon ya desinyo to et mamapaabeba met ed panaon ya ag-onkikiwas ed panagputot na dakel a rolyo ya manbibiigan.
Panagparaan na Aluminium Foil parad saray Flexible Connectors
Say aluminum foil et anlemek tan mainomay ya onkupas odino ontaynan legan ya manpapakan. Say kombinasyon na adjustable guides, material hold-down, tan servo feeding et ontulong pian mansiansian susto so posisyon na foil antis ya onsabi ed cutting blade.
Antis na batch production, nepeg ya gawaen so sample cuts unong ed kapal na foil, kondisyon na tapew, tension na roll, tan karukey na target. Say kapeles na pangipakan tan say hold-down setting et nayarin i-adjust pian mipara ed materyal.
Battery Flexible Interconnects
Diad saray aplikasyon na panagtipon na baterya tan enerhiya, say laminated copper odino aluminum foil et kaslakan ya ondalan ed nanduruman proseso, kaiba lay panagparaan na cut-ya anggad-length, panag-stack, panag-compress, panag-welding, panag-punching, tan panagporma.
Say HF-365FR et nayarin i-install ed gapo na flexible interconnect production line tan i-integrate ed downstream foil stacking, diffusion welding, punching, tan finishing ya kagawaan.
Saray Kabiangan ed Kuryenti tan Panangibunog na Kuryenti
Say makina et makapanggawa met na manipis iran copper tan aluminum strips ya uusaren ed switchgear, transformer, distribution equipment, tan power electronics. Saray parametro na produksyon parad saray mabetbet ya gagawaen ya parte et nayarin isimpen odino i-re-maples ya i-re-enter, ya mamawas ed panaon na pangi-setup no man-switch ed baetan na saray specifications.
Saray Manunan Gawaen tan Saray Tampok na Desinyo
PLC tan Touchscreen Control
Sarag na operator ya i-set so karukey na panagputot, karakel na produksyon, tan kapeles na operasyon panamegley na touchscreen. Say sentralisadon panangontrol ed saray parametro so mamagaan ed saray trial run, pananguman na produkto, tan produksyon na batch ya mainomay ya asikasoen.
Say makina et automatikon ontunda no asumpal lay akaprograman karakel, kanian nabawasan so lingo ed panagbilang tan napaliisan so ag nakaukolan ya sobran produksyon.
Servo-Controlled Cut-to-Length Feeding
Say servo motor tan drive so mangokontrol ed karukey na pangiter na materyales panamegley na PLC program. Sayan sistema et mas matukoy ed paulit-ulit ya produksyon na nanduruman karukey na foil nen say manual ya panagsukat odino mekanikal ya panag-stop.
Say estandarten pakayarin manputot et ±0.05 mm. Say aktual ya resulta et nayarin manduruma depende ed kapal na foil, tension na roll, kondisyon na tapew, kapeles na pangipakan, tan say akaprograman karukey.
Saray Giya ed Materyal ya Nayarin I-adjust
Saray metal ya giya et nayarin i-adjust pian onkana ed nanduruman kalapar na materyales tan mansiansian aka-align so foil legan ya onloloob ed saray seksion na panagpakan tan panagputot.
Kayari na panguman na saray rolyo, nepeg ya nengnengen so clearance na giya. Say alablabas ya kaarawi et nayarin mamaabuloy ed materyal ya onaanod, bangta say kulang ya kaarawi et nayarin maneral ed saray gilig na foil odino mamarakep ed resistensya na panagpakan.
Koordinadon Panag-ipit tan Pan-cut na Materyal
Say dedikadon hold-down mechanism so mangiseguro ed materyal antis ya onalis so blade, ya mamawas ed posibilidad na manipis ya foil ya onkukurang odino onkupas legan ya manpuputer.
Say cutting blade et gawad alloy steel tan precision-ground. Say suston kaarawi na blade, clamping pressure, tan saray interval na maintenance et ontulong pian napansiansia so malinis ya sugat legan ya nabawasan so burrs tan curled edges.
Malet, Inkasakey ya Istruktura na Makina
Say panagkargaan na tarem tan say manunan frame na makina et manguusar na sakey a desinyo na istruktura, a walaan na makapal iran plato na asero ya mangiiter na inkapekder legan na kada siklo na panagputot.
Say malet ya frame et ontulong pian nalimitaan so iyaamot na panagputot ya sengegan na yegyeg odino depormasyon na istruktura legan na andukey a panaon ya operasyon.
Panagpaliis parad tuloytuloy ya operasyon
Saray cooling fan et ontulong pian nakontrol so temperatura na saray electrical tan drive components legan na andukey ya panaon na produksyon. Nepeg ya walay magenap ya dagem ed kaliberliber na makina, tan nepeg ya regular ya ekalen so dabok ed saray bentilador, filter, tan electrical cabinet.
Deskripsion na saray produkto
|
Kabiangan |
Tatak |
Nanlapuan |
|
Touch Screen |
Kunlun Tongtai (MCGS) |
Tsina |
|
PLC |
Mitsubishi |
Hapon |
|
AC Motor |
Panag-apog |
Taiwan, China |
|
Panputot na Talim |
Daido |
Hapon |
|
Servo Driver |
Tonghang |
Tsina |
|
Servo Motor |
Tonghang |
Tsina |
|
Relay |
Schneider |
France |
Saray electrical components tan istruktura na makina et nayarin i-update bilang kabiangan na tuloytuloy ya panagpaalagey na produkto. Say pinal ya configuration et base ed technical agreement tan order documents ya inaprobaan na duaran partido.
Teknikal iran Detalyado
|
Parametro |
Espesipikasyon |
|
Modelo |
HF-365FR |
|
Karukey na Panputot |
1 – 9999.9 mm |
|
Lapar na Panputot |
1 – 365mm |
|
Inkaepektibo ed Panputot |
1 – 1200pcs/min (Adjustable) |
|
Inkasusto na Panputot |
±0.05 mm |
|
Kapal na Panputot |
0.01 – 0.3mm |
|
Max. Material Rack Load |
50 kg (Single axis) |
|
Diametro na Loob na Materyal |
74-79mm |
|
Kabuoan na Pakayarian |
3.6kW |
|
boltahe |
220V |
|
Belat |
380kg |
|
Sukat (L×W×H) |
2500 × 1000 × 1200 mm |
Say nibaga ya cutting rate et say nauman ya operating range na makina tan agto labay ya ibagan say sankatageyan ya output et naabot ed kada materyal odino karukey na panagputot. Say aktual ya kapeles na produksyon et mandedepende ed karukey, kalapar, kapal, bilang na saray rolyo ya iproseso, tan say paraan na panagkolekta na materyales.
Saray Problema ed Produksyon ya Ontulong ya Naresolbe na HF-365FR
Ag-ontutundan Karukey Lapud Manual ya Pansukat
Say servo-controlled feeding et mamaabuloy ed makina ya uliten so akaprograman karukey na panagputot, ya mamapaabeba ed pandurumaan na sukat ya misiglaotan ed tape measurement, manual stops, odino panangukom na operator.
01
Makapuy ya Pan-align na saray aka-stack ya foil layers
Say mas pareparehon karukey na foil et mamagaan ed panag-stack tan pangipuesto ed sampot. Parad saray kurbadon nababalang ya konektor, say incremental-length programming et makapangiter met na nakaukolan ya bayad ed baetan na saray layer.
02
Panaon ya Naandi No Manproproseso na Saray Rolyo na Indibidual
Apatiran istasyon na materyales so mangiiter na pankanawnawan nakarga tan naproseso so dakel a rolyo ed loob na parehon siklo na produksyon, ya mamaaligwas ed inkaepektibo na panagparaan parad saray laminated copper tan aluminum flexible connectors.
03
Basura na Materyal Kayari na Saray Inkaabala ed Produksyon
Say pause protection tan data retention et ontulong pian makapawil so makina manlapud dugan punto na produksyon, ya nabawasan so basura manlapud paulit-ulit ya pangipakan, pangibilang lamet, tan kaaruman iran setup cuts.
04
Aliwan Malet ya Panagparaan na Materyal Antis ya Man-welding
Say pareparehon karukey na foil, kalidad na panagputot, tan inkapatat so mangiiter na mas napanmatalkan a basiyan parad ontumbok ya panag-stack, panag-clamp, diffusion welding, tan panag-punching. Anggaman say cutting machine et agto nadetermina so pinal ya kalidad na welding, nabawasan to ray problema ed posisyon ya sengegan na ag-inkayadyari na panagparaan ed tagey.
05
Akin ya pilien so HAIFEI
Say HAIFEI et aglabat mansusuplay na makinan panagputot na copper foil. Say eksperiensya mi et mansaklaw met na saray kagawaan parad copper tan aluminum flexible busbars, laminated conductive connectors, solid busbars, tan arum niran kabiangan ya uusaren ed saray aplikasyon na kuryente tan balon enerhiya.
No manpipili na makina, ikonsidera na saray inhinyero mi no panon ya apektaen na proseso na panagputot so ontumbok ya panag-stack tan panag-welding. Say karukey na foil, bilang na saray layer, paraan na panag-stack, weld area, tan say finish-geometry na parte et repasoen ya saniiba imbes ya pilien so makina base labat ed kalapar na materyal.
Kaiba ed saray naala ya suporta ed proyekto:
- Panrepaso ed aplikasyon base ed saray detalye na materyales tan saray drowing na produkto;
- Trial cutting na copper tan aluminum foil;
- Ebalwasyon na incremental-leth ya programa;
- Say pangitunos ed saray kagawaan ed panag-welding ed leksab na ilog;
- Saray nipasal ya unwind stand, giya na materyales, tan sistema na panagkolekta;
- Pre-pansubok tan panangabobon na sample na makina antis na kargamento;
- Giya ed pangipaalagey, panag-operate, tan panagmintina;
- Rekomendasyon ed ekstran blade tan wear-part.
Saray sertipikasyon
Akapanserbisyo kami ed masulok ya 5,000+ ya kustomer ed interon mundo, tan saray abayag lan kasosyo mi et kaiba so Tesla, BYD, tan Siemens.
Masulok ya 50+ Fortune 500 ya kompanya.
Saray Kasosyo Mi
40+ Patents tan 2 National Software Copyrights, 10,000m2 Pabrika ya walay 100+ marunong ya empleyado.
Customer site
FAQ
T: Sarag kasi na HF-365FR ya putoten so apatiran rolyo na copper foil ya mankakasakey?
A: On. Say makina et walaan na apatiran istasyon na pangilukas na materyales tan sarag ton iproseso so anggad apatiran rolyo ed loob na parehon siklo na panagputot. Say kalapar, belat, tan inkauksoy na rolyo et nepeg ya mansiansia ed loob na epektibon kapasidad na makina.
T: Sarag kasi na sayan makina ya putoten so aluminum foil?
A: On. Say HF-365FR et matukoy parad saray kaslakan ya copper tan aluminum foil. Lapud medyo anlemek so aluminum foil, nirekomenda so trial cutting pian naseguro so suston kapeles na pangipakan, pangigiya na clearance, tan hold-down setting.
T: Antoy estandarten kapal na materyales?
A: Say estandarten kapal et 0.01-0.3 mm. Saray materyales ya walad paway na sayan sakop et mankaukolan na nikaduman panangusisa ed blade, mekanismo na pangipakan, tan istruktura na makina.
T: Sarag kasi na makina ya putoten so foil ed nanduruman karukey?
A: On. Say karukey tan karakel na panagputot et nayarin iprograma panamegley na touchscreen. Say incremental-length cutting et wala met parad saray nababalang ya konektor ya mankaukolan na length compensation ed baetan na saray layers.
T: Antoy nagawaan na HF-365FR ed panagputot?
A: Say estandarten pakayarin manputot et ±0.05 mm. Say aktual ya resulta et mandedepende ed kapal na foil, tension na roll, kondisyon na tapew, kapeles na pangipakan, tan karukey na panagputot.
Q: Wala kasi ray burrs na pinuter ya copper foil?
A: Say makina et manguusar na material hold-down mechanism tan sakey ya alloy-steel cutting blade pian nawalaan na malinis ya gilig no duga so pangi-adjust. Say pakasulong na blade, lingon clearance, odino ag-regular a materyal et nayarin mangapekta nin siansia ed kalidad na gilig, kanian kaukolan so naynay ya inspeksion tan panmintina.
